该系列挤出机适用于各种热塑性塑料：PVC、PE、PP、PC、ABS、PA等，配上各种成型辅机和模具即可生产各种管材、棒材、板材、异型材、片材、薄膜、造粒、拉丝、电线电缆和中空制品等等，用途广泛。
The extrudes of SJseries are primarily used to extrusion thermoplastic products.Epuipped with appropriate Screw、,head--dies and auxiliary equipment,it can turu the PVC PE PP PC ABS PA into plastic products ,such as tubes ,rods,plates,profiles,sheets,films,pellets,monofilaments,wires--coating and hollow plastic products,etc.
|
型 号Model |
螺杆直径（mm） Screwdia |
螺杆长径比（L/D) Screw ratio |
螺杆转速（r/min） Screw speed |
产量（kg）Out put |
|
SJ20*25 |
Φ20 |
1:25 |
10-60 |
0.5-5 |
|
SJ30*25 |
Φ30 |
1:25 |
10-90 |
2-10 |
|
SJ30*28 |
Φ30 |
1:28 |
10-90 |
2-10 |
|
SJ45*25 |
Φ45 |
1:25 |
10-90 |
8-20 |
|
SJ45*28 |
Φ45 |
1:28 |
10-60 |
38 |
|
SJ45*30 |
Φ45 |
1:30 |
8-80 |
38 |
|
SJ50*28 |
Φ50 |
1:28 |
6-60 |
45 |
|
SJ55*28 |
Φ55 |
1:28 |
6-60 |
45 |
|
SJ65*25 |
Φ65 |
1:25 |
8-90 |
50 |
|
SJ65*28 |
Φ65 |
1:28 |
8-90 |
80 |
|
SJ65*30 |
Φ65 |
1:30 |
8-80 |
80 |
|
SJ70*30 |
Φ70 |
1:30 |
6-60 |
100 |
|
SJ80*28 |
Φ80 |
1:28 |
6-60 |
150 |
|
SJ90*25 |
Φ90 |
1:25 |
6-60 |
200 |
|
SJ120*25 |
Φ120 |
1:25 |
8-42 |
250 |
|
SJ150*25 |
Φ150 |
1:25 |
8-42 |
300 |
|
SJ200*25 |
Φ200 |
1:25 |
4-40 |
450 |
